NRF51822-CTAC-R7

Active

Nordic Semiconductor ASA

IC RF TXRX BLE 48QFN

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

NRF51822-CTAC-R7

Active

Nordic Semiconductor ASA

IC RF TXRX BLE 48QFN

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	1500	$ 2.75

Description

General part information

NRF51822 Series

IC RF TxRx Only Bluetooth, General ISM > 1GHz Bluetooth v4.1 2.4GHz 48-VFQFN Exposed Pad

Documents

Technical documentation and resources

Datasheet

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	NRF51822-CTAC-R7	NRF51822 Series

Current - Receiving	-	9.7 mA
Current - Receiving	-	13.4 mA
Current - Transmitting [Max]	16 mA	16 mA
Current - Transmitting [Min]	4.7 mA	4.7 mA
Data Rate (Max)	2 Mbps	2 Mbps
Frequency	2.4 GHz	2.4 GHz
GPIO	31	31 - 32
Memory Size	-	8 - 256 kB
Memory Size [custom]	16 kB	16 kB
Memory Size [custom]	256 kB	256 kB
Modulation	GFSK	GFSK
Mounting Type	Surface Mount	Surface Mount
Operating Temperature [Max]	75 ░C	75 ░C
Operating Temperature [Min]	-25 °C	-25 °C
Package / Case	48-VFQFN Exposed Pad	WLCSP, 56-UFBGA, 48-VFQFN Exposed Pad, 62-UFBGA
Power - Output	4 dBm	4 dBm
Protocol	Bluetooth v4.1	Bluetooth v4.0, Bluetooth v4.1
RF Family/Standard	General ISM > 1GHz, Bluetooth	General ISM > 1GHz, Bluetooth
Serial Interfaces	UART, I2C, SPI	UART, I2C, SPI
Supplier Device Package	48-QFN (6x6)	56-WLCSP, 48-QFN (6x6), 62-WLCSP
Supplier Device Package	-	3.5 - 3.83
Supplier Device Package	-	3.33 - 3.83
Type	TxRx Only	TxRx Only
Voltage - Supply [Max]	3.6 V	3.6 V
Voltage - Supply [Min]	1.8 V	1.8 V

NRF51822 Series

IC RF TXRX BLE 56WLCSP

Part	Supplier Device Package [x]	Supplier Device Package [y]	Supplier Device Package	GPIO	Modulation	Voltage - Supply [Max]	Voltage - Supply [Min]	Data Rate (Max)	RF Family/Standard	Type	Mounting Type	Current - Receiving [Min]	Current - Receiving [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Frequency	Serial Interfaces	Current - Transmitting [Min]	Current - Transmitting [Max]	Protocol	Memory Size	Power - Output	Package / Case	Memory Size [custom]	Memory Size [custom]
Nordic Semiconductor ASA NRF51822-CDAB-R	3.5	3.33	56-WLCSP	32	GFSK	3.6 V	1.8 V	2 Mbps	Bluetooth, General ISM > 1GHz	TxRx Only	Surface Mount	9.7 mA	13.4 mA	-25 °C	75 ░C	2.4 GHz	I2C, SPI, UART	4.7 mA	16 mA	Bluetooth v4.0	16 kB, 128 kB	4 dBm	56-UFBGA, WLCSP
Nordic Semiconductor ASA NRF51822-QFAB-R7			48-QFN (6x6)	32	GFSK	3.6 V	1.8 V	2 Mbps	Bluetooth, General ISM > 1GHz	TxRx Only	Surface Mount	9.7 mA	13.4 mA	-25 °C	75 ░C	2.4 GHz	I2C, SPI, UART	4.7 mA	16 mA	Bluetooth v4.0	16 kB, 128 kB	4 dBm	48-VFQFN Exposed Pad
Nordic Semiconductor ASA NRF51822-QFAC-T			48-QFN (6x6)	32	GFSK	3.6 V	1.8 V	2 Mbps	Bluetooth, General ISM > 1GHz	TxRx Only	Surface Mount	9.7 mA	13.4 mA	-25 °C	75 ░C	2.4 GHz	I2C, SPI, UART	4.7 mA	16 mA	Bluetooth v4.0	32 kB, 256 kB	4 dBm	48-VFQFN Exposed Pad
Nordic Semiconductor ASA NRF51822-QFAB-T			48-QFN (6x6)	32	GFSK	3.6 V	1.8 V	2 Mbps	Bluetooth, General ISM > 1GHz	TxRx Only	Surface Mount	9.7 mA	13.4 mA	-25 °C	75 ░C	2.4 GHz	I2C, SPI, UART	4.7 mA	16 mA	Bluetooth v4.0	16 kB, 128 kB	4 dBm	48-VFQFN Exposed Pad
Nordic Semiconductor ASA NRF51822-QFAB-R			48-QFN (6x6)	32	GFSK	3.6 V	1.8 V	2 Mbps	Bluetooth, General ISM > 1GHz	TxRx Only	Surface Mount	9.7 mA	13.4 mA	-25 °C	75 ░C	2.4 GHz	I2C, SPI, UART	4.7 mA	16 mA	Bluetooth v4.0	16 kB, 128 kB	4 dBm	48-VFQFN Exposed Pad
Nordic Semiconductor ASA NRF51822-QFAC-R7			48-QFN (6x6)	32	GFSK	3.6 V	1.8 V	2 Mbps	Bluetooth, General ISM > 1GHz	TxRx Only	Surface Mount	9.7 mA	13.4 mA	-25 °C	75 ░C	2.4 GHz	I2C, SPI, UART	4.7 mA	16 mA	Bluetooth v4.0	32 kB, 256 kB	4 dBm	48-VFQFN Exposed Pad
Nordic Semiconductor ASA NRF51822-QFAA-R7			48-QFN (6x6)	32	GFSK	3.6 V	1.8 V	2 Mbps	Bluetooth, General ISM > 1GHz	TxRx Only	Surface Mount	9.7 mA	13.4 mA	-25 °C	75 ░C	2.4 GHz	I2C, SPI, UART	4.7 mA	16 mA	Bluetooth v4.0		4 dBm	48-VFQFN Exposed Pad	16 kB	256 kB
Nordic Semiconductor ASA NRF51822-CFAC-R	3.83	3.83	62-WLCSP	32	GFSK	3.6 V	1.8 V	2 Mbps	Bluetooth, General ISM > 1GHz	TxRx Only	Surface Mount	9.7 mA	13.4 mA	-25 °C	75 ░C	2.4 GHz	I2C, SPI, UART	4.7 mA	16 mA	Bluetooth v4.0	32 kB, 256 kB	4 dBm	62-UFBGA, WLCSP
Nordic Semiconductor ASA NRF51822-CEAA-R	3.5	3.83	62-WLCSP	32	GFSK	3.6 V	1.8 V	2 Mbps	Bluetooth, General ISM > 1GHz	TxRx Only	Surface Mount	9.7 mA	13.4 mA	-25 °C	75 ░C	2.4 GHz	I2C, SPI, UART	4.7 mA	16 mA	Bluetooth v4.0		4 dBm	62-UFBGA, WLCSP	16 kB	256 kB
Nordic Semiconductor ASA NRF51822-CTAC-R			48-QFN (6x6)	31	GFSK	3.6 V	1.8 V	2 Mbps	Bluetooth, General ISM > 1GHz	TxRx Only	Surface Mount			-25 °C	75 ░C	2.4 GHz	I2C, SPI, UART	4.7 mA	16 mA	Bluetooth v4.1		4 dBm	48-VFQFN Exposed Pad	16 kB	256 kB
