034001000800
ActiveIndustrial Shields
ESP32 ETHER&WIFI&BT PLC 57AAR I/
034001000800
ActiveIndustrial Shields
ESP32 ETHER&WIFI&BT PLC 57AAR I/
Description
General part information
034001000800
Programmable Logic Controller (PLC) DIN Rail 12 ~ 24VDC
Technical Specifications
Parameters and characteristics for this part
| Specification | 034001000800 |
|---|---|
| Communications | USB, RS-232, RS-485, Ethernet |
| Input Types | Analog/Digital, Digital |
| Maximum Expandable Modules | 127 Modules |
| Mounting Type | DIN Rail |
| Number of Digital Inputs | 16 |
| Number of Inputs | 32 |
| Number of Outputs | 27 |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | 0 °C |
| Output Type | Relay, Analog/Digital |
| Relay Outputs | 15 |
| Voltage - Supply (Maximum) | 24 VAC |
| Voltage - Supply (Minimum) | 12 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
