5434065
ActivePhoenix Contact
TERM BLOCK HDR 19POS VERT 5.08MM
5434065
ActivePhoenix Contact
TERM BLOCK HDR 19POS VERT 5.08MM
Description
General part information
5434065
19 Position Terminal Block Header, Male Pins, Shrouded (2 Side) 0.200" (5.08mm) Vertical Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 5434065 |
|---|---|
| Color | Gray |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.154 in |
| Current - IEC | 12 A |
| Current - UL | 15 A |
| Header Orientation | Vertical |
| Housing Material | Nylon, Polyamide, PA |
| Insulation Height | 0.472 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 19 |
| Pitch | 5.08 mm |
| Positions Per Level | 19 |
| Termination Style | Solder |
| Type | Male Pins, Shrouded (2 Side), Header |
| Voltage - IEC | 400 V |
| Voltage - UL | 300 V |
