7021B
ActiveEgis Mobile Electric
CONTACTOR, 250A, 12/24 V
7021B
ActiveEgis Mobile Electric
CONTACTOR, 250A, 12/24 V
Description
General part information
7021B
CONTACTOR, 250A, 12/24 V
Technical Specifications
Parameters and characteristics for this part
| Specification | 7021B |
|---|---|
| Coil Power | 1.7 W |
| Coil Voltage (Max) | 24 VAC/DC |
| Coil Voltage (Min) | 12 VAC/DC |
| Contact Form | SPST-NO |
| Contact Material | Silver Copper (AgCu3) |
| Contact Rating (Current) | 250 A |
| Features | Hermetically, Sealed |
| Form A Count | 1 |
| Mounting Type | Chassis Mount |
| Must Operate Voltage | 9 VDC |
| Must Release Voltage | 6 VDC |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Switching Voltage DC (Max) | 900 VDC |
| Termination Style | Wire Leads, Stud |
