Description
General part information
400LSU7900M77X196
7900 µF 400 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 5000 Hrs @ 85°C
Technical Specifications
Parameters and characteristics for this part
| Specification | 400LSU7900M77X196 |
|---|---|
| Applications | General Purpose |
| Capacitance | 7.9 mF |
| Height - Seated (Max) | 7.835 in |
| Lead Spacing | 1.236 in |
| Lifetime | 5000 Hrs |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -25 °C |
| Package / Case | Can - Screw Terminals, Radial |
| Polarization | Polar |
| Size / Dimension Diameter | 3.031 in |
| Tolerance | 20 % |
| Voltage - Rated | 400 V |
