MSSA-0101/C
ObsoleteAstrodyne TDI
10W ENCAPSULATED BOARD MOUNT POW
MSSA-0101/C
ObsoleteAstrodyne TDI
10W ENCAPSULATED BOARD MOUNT POW
Description
General part information
MSSA-0101/C
Enclosed AC DC Converters 1 Output 5V 2A 90 ~ 264 VAC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | MSSA-0101/C |
|---|---|
| Applications | Medical |
| Approval Agency | cURus, TUV, CE |
| Current - Output (Max) | 2 A |
| Efficiency | 80 % |
| Features | Universal Input, Adjustable Output |
| Line Regulation | 0.3 % |
| Load Regulation (Percent) | 0.3 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | 0 °C |
| Package Leads | 6 Leads |
| Package Name | 10-DIP Module |
| Power (Watts) | 10 W |
| Size / Dimension Height | 0.83 in |
| Size / Dimension Length | 2.56 in |
| Size / Dimension Width | 1.77 in |
| Standard Number | 60601-1 |
| Type | Enclosed |
| Voltage - Input (AC) Maximum | 264 V |
| Voltage - Input (AC) Minimum | 90 V |
| Voltage - Output 1 | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
