PS0SSSSXA

Active

TE Connectivity Raychem Cable Protection

PWR ENT MOD RCPT IEC320-C14 PNL

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

PWR ENT MOD RCPT IEC320-C14 PNL

Technical Specifications

Parameters and characteristics for this part

Specification	PS0SSSSXA

Accomodates a Fuse	True
Approval Agency	UL, VDE, CSA
Connector Style	IEC 320-C14
Connector Type	Receptacle, Male Blades - Module
Current Rating - Appliance Inlet	10 A
Current Rating - Filter	10 A
Features	Conversion Clip, Shielded, Voltage Selector
Filter Type	Filtered (EMI, RFI) - Commercial
Fuse Holder, Drawer	Fuse Holder
Mounting Type	Panel Mount, Snap-In
Panel Cutout Dimensions	Variable Size
Panel Thickness [Max]	2.9 mm
Panel Thickness [Max]	0.114 in
Panel Thickness [Min]	0.79 mm
Panel Thickness [Min]	0.031 "
Switch Features	Switch On-Off
Termination	0.187 "
Termination	4.7 mm
Termination	Quick Connect
Voltage Rating - Appliance Inlet	120 VAC

Part	Mounting Type	Current Rating - Filter	Panel Thickness [Max]	Panel Thickness [Max]	Panel Thickness [Min]	Panel Thickness [Min]	Connector Style	Termination	Termination	Termination	Accomodates a Fuse	Approval Agency	Current Rating - Appliance Inlet	Fuse Holder, Drawer	Connector Type	Voltage Rating - Appliance Inlet	Features	Panel Cutout Dimensions	Switch Features	Filter Type
TE Connectivity Raychem Cable Protection PS0SSSSXA	Panel Mount Snap-In	10 A	2.9 mm	0.114 in	0.79 mm	0.031 "	IEC 320-C14	0.187 "	4.7 mm	Quick Connect		CSA UL VDE	10 A	Fuse Holder	Receptacle Male Blades - Module	120 VAC	Conversion Clip Shielded Voltage Selector	Variable Size	Switch On-Off	Filtered (EMI RFI) - Commercial

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Power Entry Connector Receptacle, Male Blades - Module IEC 320-C14 Panel Mount, Snap-In
