Specification	TSX-3225 48.00M-90AAFFG40REB

ESR (Equivalent Series Resistance)	40 Ohm
Frequency	48 MHz
Frequency Stability	15 ppm
Frequency Tolerance	10 ppm
Height - Seated (Max)	0.024 in
Load Capacitance	9 pF
Mounting Type	Surface Mount
Operating Mode	Fundamental
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package / Case	4-SMD, No Lead
Package Length	3.2 mm
Package Name	4-SMD
Package Width	2.5 mm
Size / Dimension Length	0.126 in
Size / Dimension Width	0.098 in
Type	MHz Crystal

TSX-3225 Series

...

Part	Operating Mode	ESR (Equivalent Series Resistance)	Package / Case	Type	Mounting Type	Height - Seated (Max)	Size / Dimension Width	Size / Dimension Length	Frequency	Load Capacitance	Operating Temperature (Min)	Operating Temperature (Max)	Frequency Stability	Package Length	Package Name	Package Width	Frequency Tolerance
EPSON TSX-3225 20.0000ME20X-K6	Fundamental	60 Ohm	4-SMD No Lead	MHz Crystal	Surface Mount	0.024 in	0.098 in	0.126 in	20 MHz	10 pF	-40 °C	85 °C	20 ppm	3.2 mm	4-SMD	2.5 mm	15 ppm
EPSON TSX-3225 40.0000MF18X-C	Fundamental	40 Ohm	4-SMD No Lead	MHz Crystal	Surface Mount	0.024 in	0.098 in	0.126 in	40 MHz	18 pF	-40 °C -20 °C	70 °C 85 °C	10 ppm 18 ppm	3.2 mm	4-SMD	2.5 mm	10 ppm
EPSON TSX-3225 32.0000MF18X-AJ3	Fundamental	40 Ohm	4-SMD No Lead	MHz Crystal	Surface Mount	0.024 in	0.098 in	0.126 in	32 MHz	8 pF 18 pF	-40 °C -20 °C	70 °C 85 °C	10 ppm 18 ppm	3.2 mm	4-SMD	2.5 mm	10 ppm
EPSON TSX-3225 40.0000MF10Z-AC	Fundamental	40 Ohm	4-SMD No Lead	MHz Crystal	Surface Mount	0.024 in	0.098 in	0.126 in	40 MHz	9 pF	-20 °C	75 °C	10 ppm	3.2 mm	4-SMD	2.5 mm	10 ppm
EPSON TSX-3225 19.2000MF12Y-AGX GPS	Fundamental	60 Ohm	4-SMD No Lead	MHz Crystal	Surface Mount	0.024 in	0.098 in	0.126 in	19.2 MHz	7 pF 12 pF	-30 °C -20 °C	70 °C 85 °C	10 ppm 12 ppm	3.2 mm	4-SMD	2.5 mm	10 ppm
EPSON TSX-3225 27.0000MF10Z-W3	Fundamental	40 Ohm	4-SMD No Lead	MHz Crystal	Surface Mount	0.024 in	0.098 in	0.126 in	27 MHz	10 pF 12 pF	-20 °C	70 °C 75 °C	10 ppm	3.2 mm	4-SMD	2.5 mm	10 ppm
EPSON TSX-3225 25.0000MF10C-W3	Fundamental	40 Ohm	4-SMD No Lead	MHz Crystal	Surface Mount	0.024 in	0.098 in	0.126 in	25 MHz	12 pF	0 °C	85 °C	10 ppm	3.2 mm	4-SMD	2.5 mm	10 ppm
EPSON TSX-3225 48.0000MF10Z-B0	Fundamental	40 Ohm	4-SMD No Lead	MHz Crystal	Surface Mount	0.024 in	0.098 in	0.126 in	48 MHz	16 pF	-20 °C	75 °C	10 ppm	3.2 mm	4-SMD	2.5 mm	10 ppm
EPSON TSX-3225 27.0000MF18X-C	Fundamental	40 Ohm	4-SMD No Lead	MHz Crystal	Surface Mount	0.024 in	0.098 in	0.126 in	27 MHz	18 pF	-40 °C	85 °C	18 ppm	3.2 mm	4-SMD	2.5 mm	10 ppm
EPSON TSX-3225 38.4000MF15Y-AJ3	Fundamental	40 Ohm	4-SMD No Lead	MHz Crystal	Surface Mount	0.024 in	0.098 in	0.126 in	38.4 MHz	8 pF 15 pF	-30 °C -20 °C	70 °C 85 °C	10 ppm 15 ppm	3.2 mm	4-SMD	2.5 mm	10 ppm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

TSX-3225 48.00M-90AAFFG40REB | Datasheet
