BUL810
ObsoleteSTMicroelectronics
TRANS GP BJT NPN 450V 15A 3-PIN(3+TAB) TO-247 TUBE
BUL810
ObsoleteSTMicroelectronics
TRANS GP BJT NPN 450V 15A 3-PIN(3+TAB) TO-247 TUBE
Description
General part information
BUL810
High voltage capability
Low spread of dynamic parameters
Low base-drive requirements
Technical Specifications
Parameters and characteristics for this part
| Specification | BUL810 |
|---|---|
| Current - Collector (Ic) (Max) | 15 A |
| Current - Collector Cutoff (Max) | 250 µA |
| DC Current Gain (hFE) (Min) | 10 |
| Mounting Type | Through Hole |
| Operating Temperature | 150 °C |
| Package / Case | TO-247-3 |
| Package Name | TO-247-3 |
| Power - Max | 125 W |
| Transistor Type | NPN |
| Vce Saturation (Max) | 5 V |
| Voltage - Collector Emitter Breakdown (Max) | 450 V |
