MAX9788EVKIT+
ActiveAnalog Devices Inc./Maxim Integrated
EVALUATION KIT FOR MAX9788
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAX9788EVKIT+
ActiveAnalog Devices Inc./Maxim Integrated
EVALUATION KIT FOR MAX9788
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX9788EVKIT+ | MAX9788 Series |
|---|---|---|
| Amplifier Type | Class G | Class G |
| Board Type | Fully Populated | Fully Populated |
| Features | - | Differential Inputs, Depop, Shutdown |
| Max Output Power x Channels @ Load | 2.4 W | 2.4 W |
| Max Output Power x Channels @ Load [custom] | 1 | 1 |
| Mounting Type | - | Surface Mount |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Output Type | 1-Channel (Mono) | 1-Channel (Mono) |
| Package / Case | - | 20-WFBGA, WLBGA, 28-WFQFN Exposed Pad |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 20-WLP, 28-TQFN (5x5) |
| Type | - | Class G |
| Utilized IC / Part | MAX9788 | MAX9788 |
| Voltage - Supply [Max] | 5.5 V | 5.5 V |
| Voltage - Supply [Min] | 2.7 V | 2.7 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 75.32 | |
MAX9788 Series
IC AMP CLASS G MONO 2.4W 20WLP
| Part | Type | Voltage - Supply [Min] | Voltage - Supply [Max] | Output Type | Supplier Device Package | Operating Temperature [Max] | Operating Temperature [Min] | Features | Mounting Type | Package / Case | Max Output Power x Channels @ Load [custom] | Max Output Power x Channels @ Load | Board Type | Amplifier Type | Supplied Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX9788EWP+TG45 | Class G | 2.7 V | 5.5 V | 1-Channel (Mono) | 20-WLP | 85 °C | -40 °C | Depop, Differential Inputs, Shutdown | Surface Mount | 20-WFBGA, WLBGA | 1 | 2.4 W | ||||
Analog Devices Inc./Maxim Integrated MAX9788EVKIT+ | 2.7 V | 5.5 V | 1-Channel (Mono) | 1 | 2.4 W | Fully Populated | Class G | Board(s) | MAX9788 | |||||||
Analog Devices Inc./Maxim Integrated MAX9788EBP+T | Class G | 2.7 V | 5.5 V | 1-Channel (Mono) | 20-WLP | 85 °C | -40 °C | Depop, Differential Inputs, Shutdown | Surface Mount | 20-WFBGA | 1 | 2.4 W | ||||
Analog Devices Inc./Maxim Integrated MAX9788ETI+T | Class G | 2.7 V | 5.5 V | 1-Channel (Mono) | 28-TQFN (5x5) | 85 °C | -40 °C | Depop, Differential Inputs, Shutdown | Surface Mount | 28-WFQFN Exposed Pad | 1 | 2.4 W |
Description
General part information
MAX9788 Series
MAX9788 - 1-Channel (Mono) Output Class G Audio Amplifier Evaluation Board
