5445135
ActivePhoenix Contact
TERM BLOCK HDR 13POS 90DEG 5MM
5445135
ActivePhoenix Contact
TERM BLOCK HDR 13POS 90DEG 5MM
Description
General part information
5445135
13 Position Terminal Block Header, Male Pins, Shrouded (2 Side) 0.197" (5.00mm) 90°, Right Angle Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 5445135 |
|---|---|
| Color | Green |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.138 in |
| Current - IEC | 12 A |
| Current - UL | 15 A |
| Header Orientation | Right Angle |
| Header Orientation Angle | 90 ° |
| Housing Material | Nylon, Polyamide, PA |
| Insulation Height | 0.339 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 13 |
| Pitch | 0.197 in |
| Positions Per Level | 13 |
| Termination Style | Solder |
| Type | Male Pins, Shrouded (2 Side), Header |
| Voltage - IEC | 400 V |
| Voltage - UL | 300 V |
