Description

General part information

G128ALGFGSW6WTC3XAM

Non-Touch Graphic LCD Display Module Transflective White FSTN - Film Super-Twisted Nematic I2C, SPI 3.5" (89.24mm) 128 x 128

Technical Specifications

Parameters and characteristics for this part

SpecificationG128ALGFGSW6WTC3XAM
Background ColorGray
Backlight ColorWhite
Backlight TypeLED
Controller TypeST7528i
Diagonal Screen Size3.5 in
Display ModeTransflective
Display TypeFSTN - Film Super-Twisted Nematic
Dot Pitch Height0.44 mm
Dot Pitch Width0.44 mm
Dot Pixels (Horizontal)128 pixels
Dot Pixels (Vertical)128 pixels
Dot Size Height0.42 mm
Dot Size Width0.42 mm
Graphics ColorWhite
InterfaceI2C, SPI
TouchscreenNon-Touch
Viewing Area Height60.61 mm
Viewing Area Width65.5 mm
