FMCN1831
ObsoleteFairview Microwave
CONN JACK CRIMP/SOLDER 7/16 DIN
FMCN1831
ObsoleteFairview Microwave
CONN JACK CRIMP/SOLDER 7/16 DIN
Description
General part information
FMCN1831
7/16 DIN Connector Jack, Female Socket 50 Ohms Free Hanging (In-Line) Solder
Technical Specifications
Parameters and characteristics for this part
| Specification | FMCN1831 |
|---|---|
| Body Finish | Tri-Metal |
| Body Material | Brass |
| Cable Group | 141, RG-58, LMR-195, 303 |
| Center Contact Material | Copper |
| Center Contact Plating | Tri-Metal |
| Connector Style | 7/16 DIN |
| Connector Type | Jack, Female Socket |
| Contact Termination | Solder |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Fastening Type | Threaded |
| Frequency - Max | 3 GHz |
| Housing Color | Silver |
| Impedance | 50 Ohm |
| Mounting Type | Free Hanging (In-Line) |
| Number of Ports | 1 |
| Shield Termination | Crimp |
