290296 Series

Part	Circuit	Voltage - Load (Min)	Voltage - Load (Max)	Mounting Type	Package / Case	Voltage - Input	Operating Temperature (Max)	Operating Temperature (Min)	Output Type	Load Current	Approval Agency	Termination Style
Phoenix Contact 2982786	SPST-NO (1 Form A)	3 V	33 V	DIN Rail	Module	24 V	60 °C	-20 °C	DC	5 A	EN IEC	Screw Terminal
Phoenix Contact 2982728	SPST-NO (1 Form A)	0 V	5 V	DIN Rail	Module	24 V	60 °C	-20 °C	DC		EN IEC	Screw Terminal
Phoenix Contact 2966634	SPST-NO (1 Form A)	3 V	33 V	DIN Rail	Module	24 V	60 °C	-20 °C	DC	3 A	EN IEC	Screw Terminal
Phoenix Contact 2980694	SPST-NO (1 Form A)	12 V	300 V	DIN Rail	Module	110 VAC	60 °C	-20 °C	DC	1000 mA	EN IEC	Screw Terminal
Phoenix Contact 2902964	SPST-NO (1 Form A)	4 V	30 V	DIN Rail	Module	24 V	60 °C	-20 °C	DC	50 mA	EN	Screw Terminal
Phoenix Contact 2980610	SPST-NO (1 Form A)	3 V	33 V	DIN Rail	Module	24 V	60 °C	-20 °C	DC	3 A	EN IEC	Screw Terminal
Phoenix Contact 2967879	SPST-NO (1 Form A)	24 V	253 V	DIN Rail	Module	120 VAC	60 °C	-20 °C	AC	750 mA	EN IEC	Screw Terminal
