NES-35-24
ObsoleteMEAN WELL USA Inc.
AC/DC CONVERTER 24V 36W
NES-35-24
ObsoleteMEAN WELL USA Inc.
AC/DC CONVERTER 24V 36W
Description
General part information
NES-35-24
Enclosed AC DC Converters 1 Output 24V 85 ~ 264 VAC, 120 ~ 370 VDC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | NES-35-24 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | cURus, CB, CCC |
| Current - Output 1 | 1.5 A |
| Efficiency | 85 % |
| Features | Universal Input, Adjustable Output |
| Minimum Load Required | No |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -20 °C |
| Power (Watts) | 36 W |
| Size / Dimension Height | 1.42 in |
| Size / Dimension Length | 3.9 in |
| Size / Dimension Width | 3.82 in |
| Type | Enclosed |
| Voltage - Input (AC) Maximum | 264 V |
| Voltage - Input (AC) Minimum | 85 VAC |
| Voltage - Input (DC) Maximum | 370 V |
| Voltage - Input (DC) Minimum | 120 V |
| Voltage - Isolation | 3 kV |
| Voltage - Output 1 | 24 V |
