Description
General part information
MS24266R18B14SN
PLUG 14 POS SOCKET BAYONET
Technical Specifications
Parameters and characteristics for this part
| Specification | MS24266R18B14SN |
|---|---|
| Cable Opening | 0.902 in |
| Connector Type | Female Sockets, Plug |
| Contact Finish - Mating | Gold |
| Fastening Type | Bayonet Lock |
| Features | Coupling Nut |
| Ingress Protection | Environment Sealed |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 14 |
| Operating Temperature (Max) | 200 °C |
| Operating Temperature (Min) | -55 °C |
| Orientation | N (Normal) |
| Position Types | Power |
| Primary Material | Metal |
| Shell Finish | Anodized |
| Shell Material | Aluminum |
| Shell Size - Insert Length | 18 mm |
| Shell Size - Insert Width | 14 mm |
| Shell Size (MIL) | F |
| Shielding | Unshielded |
| Termination | Crimp |
