V1597S8-400-550K
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
FREQUENCY :400~550, VDD:3~6, VC:
V1597S8-400-550K
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
FREQUENCY :400~550, VDD:3~6, VC:
Description
General part information
V1597S8-400-550K
Oscillator
Technical Specifications
Parameters and characteristics for this part
| Specification | V1597S8-400-550K |
|---|---|
| 2nd Harmonic (Typ) (dBc) | -15 dBc |
| Frequency Range (Max) | 550 MHz |
| Frequency Range (Min) | 400 MHz |
| Height | 0.087 in |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -30 °C |
| Package / Case | No Lead, 8-SMD |
| Size / Dimension Length | 0.354 in |
| Size / Dimension Width | 0.276 in |
| Voltage - Supply (Maximum) | 6 V |
| Voltage - Supply (Minimum) | 3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
