General part information
DIN Rail Terminal Blocks Mini Feed-through 3.5mm Width,26-14AWG
Technical documentation and resources
Parameters and characteristics for this part
| Specification | 1725740 |
|---|---|
| Color | Green |
| Current | 6 A |
| Housing Material | Polyamide (PA), Nylon |
| Mating Orientation | Horizontal with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Pitch [x] | 2.54 mm |
| Pitch [x] | 0.1 in |
| Positions Per Level | 11 |
| Screw Thread | M1.6 |
| Torque - Screw [Max] | 1.3 Lb-In |
| Torque - Screw [Max] | 0.15 Nm |
| Torque - Screw [Min] | 0.12 Nm |
| Torque - Screw [Min] | 1 Lb-In |
| Voltage | 125 V |
| Wire Gauge [Max] | 30 AWG |
| Wire Gauge [Min] | 20 AWG |
| Wire Termination | Screw |
DIN Rail Terminal Blocks Mini Feed-through 3.5mm Width,26-14AWG
| Part | Housing Material | Wire Gauge [Max] | Wire Gauge [Min] | Positions Per Level | Number of Levels | Color | Torque - Screw [Max] | Torque - Screw [Min] | Torque - Screw [Min] | Torque - Screw [Max] | Current | Pitch [x] | Pitch [x] | Voltage | Screw Thread | Wire Termination | Mating Orientation | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact 1725740 | Polyamide (PA), Nylon | 30 AWG | 20 AWG | 11 | 1 | Green | 1.3 Lb-In | 0.12 Nm | 1 Lb-In | 0.15 Nm | 6 A | 2.54 mm | 0.1 in | 125 V | M1.6 | Screw | Horizontal with Board | Through Hole |
