1N4436T

Active

Microchip Technology

BRIDGE RECTIFIER SINGLE PHASE STANDARD 200V QC TERMINAL

Search across all available documentation for this part.

Active

Microchip Technology

BRIDGE RECTIFIER SINGLE PHASE STANDARD 200V QC TERMINAL

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	1N4436T	1N4436 Series

	-	-
Current - Average Rectified (Io)	10 A	10 A
Current - Reverse Leakage @ Vr	10 µA	10 µA
Diode Type	Single Phase	Single Phase
Mounting Type	QC Terminal	Stud Mount, QC Terminal
Operating Temperature [Max]	160 °C	160 °C
Operating Temperature [Min]	-65 °C	-65 ░C
Package / Case	Module	Module
Technology	Standard	Standard
Voltage - Forward (Vf) (Max) @ If [Max]	1.2 V	1.2 V
Voltage - Peak Reverse (Max) [Max]	200 V	200 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	100	$ 177.39
Microchip Direct	N/A	1	$ 191.03
Newark	Each	100	$ 177.39
		500	$ 170.56

Bridge Rectifier Single Phase Standard 200V Stud Mount

Part	Technology	Current - Reverse Leakage @ Vr	Mounting Type	Voltage - Forward (Vf) (Max) @ If [Max]	Voltage - Peak Reverse (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Current - Average Rectified (Io)	Package / Case	Diode Type
Microchip Technology 1N4436FS
Microchip Technology 1N4436
Microchip Technology 1N4436T
Microchip Technology 1N4436	Standard	10 µA	Stud Mount	1.2 V	200 V	160 °C	-65 ░C	10 A	Module	Single Phase
Microchip Technology 1N4436T	Standard	10 µA	QC Terminal	1.2 V	200 V	160 °C	-65 °C	10 A	Module	Single Phase
Microchip Technology 1N4436FS
