Specification	1510350025

Color	Black
Connector Type	Plug, Male Blades
Contact Finish	Gold
Contact Finish Thickness	30 µin
Contact Material	Copper Alloy
Current Rating	80 A
Fastening Type	Locking Ramp
Features	Board Guide
Material - Insulation	LCP, Liquid Crystal Polymer
Mounting Type	Through Hole, Right Angle
Number of Positions	5
Number of Rows	1
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Pitch	0.433 in
Termination	Solder
Voltage Rating	600 V

151035 Series

Part	Contact Finish Thickness	Contact Finish	Voltage Rating	Fastening Type	Material - Insulation	Operating Temperature (Min)	Operating Temperature (Max)	Contact Material	Current Rating	Number of Positions	Color	Termination	Connector Type	Mounting Type	Features	Number of Rows	Pitch
Molex 1510351006	30 µin	Gold	600 V	Locking Ramp	LCP Liquid Crystal Polymer	-40 °C	105 °C	Copper Alloy	80 A	6	Black	Solder	Male Blades Plug	Right Angle Through Hole	Board Guide	1	0.433 in
Molex 1510351022										2	Black	Solder	Male Blades Plug	Right Angle Through Hole	Board Guide	1	0.433 in
Molex 1510350004	30 µin	Gold	600 V	Locking Ramp	LCP Liquid Crystal Polymer	-40 °C	105 °C	Copper Alloy	80 A	4	Black	Solder	Male Blades Plug	Right Angle Through Hole	Board Guide	1	0.433 in
Molex 1510351024	30 µin	Gold	600 V	Locking Ramp	LCP Liquid Crystal Polymer	-40 °C	105 °C	Copper Alloy	80 A	4	Black	Solder	Male Blades Plug	Right Angle Through Hole	Board Guide	1	0.433 in
Molex 1510350014	30 µin	Gold	600 V	Locking Ramp	LCP Liquid Crystal Polymer	-40 °C	105 °C	Copper Alloy	80 A	4	Black	Solder	Male Blades Plug	Right Angle Through Hole	Board Guide	1	0.433 in
Molex 1510351014	30 µin	Gold	600 V	Locking Ramp	LCP Liquid Crystal Polymer	-40 °C	105 °C	Copper Alloy	80 A	4	Black	Solder	Male Blades Plug	Right Angle Through Hole	Board Guide	1	0.433 in
Molex 1510350012	30 µin	Gold	600 V	Locking Ramp	LCP Liquid Crystal Polymer	-40 °C	105 °C	Copper Alloy	80 A	2	Black	Solder	Male Blades Plug	Right Angle Through Hole	Board Guide	1	0.433 in
Molex 1510351004	30 µin	Gold	600 V	Locking Ramp	LCP Liquid Crystal Polymer	-40 °C	105 °C	Copper Alloy	80 A	4	Black	Solder	Male Blades Plug	Right Angle Through Hole	Board Guide	1	0.433 in
Molex 1510350013	30 µin	Gold	600 V	Locking Ramp	LCP Liquid Crystal Polymer	-40 °C	105 °C	Copper Alloy	80 A	3	Black	Solder	Male Blades Plug	Right Angle Through Hole	Board Guide	1	0.433 in
Molex 1510350002	30 µin	Gold	600 V	Locking Ramp	LCP Liquid Crystal Polymer	-40 °C	105 °C	Copper Alloy	80 A	2	Black	Solder	Male Blades Plug	Right Angle Through Hole	Board Guide	1	0.433 in
