General part information
8 (4 Pair) Conductor Multi-Pair, Cat6a Cable Red 23 AWG 1000.0' (304.8m)
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | 10GX12 0021000 | 10GX12 Series |
|---|---|---|
| Cable Type | Multi-Pair, Cat6a | Multi-Pair, Cat6a |
| Conductor Insulation | Polyolefin (PO) | Polyolefin (PO) |
| Conductor Material | Copper, Bare | Copper, Bare |
| Conductor Strand | Solid | Solid |
| Features | Rip Cord | Rip Cord |
| Jacket (Insulation) Diameter [diameter] | 0.295 in | 0.295 in |
| Jacket (Insulation) Diameter [diameter] | 7.49 mm | 7.49 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC), Riser | Poly-Vinyl Chloride (PVC), Riser |
| Jacket Color | Red | Green, Red |
| Length | 1000 ft | 1000 ft |
| Length | 304.8 m | 304.8 m |
| Number of Conductors | 8 | 8 |
| Ratings | UL Style CMR | UL Style CMR |
| Usage | Network | Network |
| Voltage | 300 V | 300 V |
| Wire Gauge | 23 AWG | 23 AWG |
CABLE CAT6A 8CON 23AWG GRN 1000'
| Part | Conductor Insulation | Features | Number of Conductors | Wire Gauge | Jacket Color | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Voltage | Ratings | Length | Length | Cable Type | Conductor Material | Conductor Strand | Usage | Jacket (Insulation) Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Belden Inc. 10GX12 0051000 | Polyolefin (PO) | Rip Cord | 8 | 23 AWG | Green | 0.295 in | 7.49 mm | 300 V | UL Style CMR | 1000 ft | 304.8 m | Multi-Pair, Cat6a | Copper, Bare | Solid | Network | Poly-Vinyl Chloride (PVC), Riser |
Belden Inc. 10GX12 0021000 | Polyolefin (PO) | Rip Cord | 8 | 23 AWG | Red | 0.295 in | 7.49 mm | 300 V | UL Style CMR | 1000 ft | 304.8 m | Multi-Pair, Cat6a | Copper, Bare | Solid | Network | Poly-Vinyl Chloride (PVC), Riser |
