UT1240-7ZG

Active

Bel Power Solutions

AC/DC CONVERTER 28.25V 500W

Search across all available documentation for this part.

Active

Bel Power Solutions

AC/DC CONVERTER 28.25V 500W

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 2041.82

General part information

Enclosed, Conformal Coated AC DC Converters 1 Output 28.25V 70 ~ 140 VAC Input

Technical documentation and resources

No documents available

Parameters and characteristics commom to parts in this series

Specification	UT1240-7ZG	UT1240 Series

Applications	ITE (Commercial)	ITE (Commercial)
Approval Agency	cCSAus, CE	cCSAus, CE
Battery Cell Size	-	24 V
Battery Chemistry	-	Lead Acid
Charge Current - Max	-	14.5 A
Current - Output 1	14.5 A	14.5 A
Efficiency	91 %	91 %
Features	Universal Input, Hot Swappable, Adjustable Output, Load Sharing	LED Indicator, Universal Input, Hot Swappable, Adjustable Output, Load Sharing
Mounting Type	Chassis Mount	DIN Rail, Chassis Mount
Number of Cells	-	1
Number of Outputs	1	1
Operating Temperature [Max]	71 °C	71 °C
Operating Temperature [Min]	-25 °C	-25 °C
Power - Max	-	500 W
Power (Watts)	500 W	500 W
Size / Dimension [x]	168 mm	168 - 168.5 mm
Size / Dimension [x]	6.6 "	6.6 - 6.63 "
Size / Dimension [y]	141 mm	141 - 141.5 mm
Size / Dimension [y]	5.6 "	5.57 - 5.6 "
Size / Dimension [z]	111 mm	111 mm
Size / Dimension [z]	4.4 in	4.4 in
Termination Style	-	Terminal Block
Type	Conformal Coated, Enclosed	Enclosed, Conformal Coated
Voltage - Input [Max]	140 VAC	140 - 255 VAC
Voltage - Input [Min]	70 VAC	70 - 85 VAC
Voltage - Isolation	2.8 kV	2.8 kV
Voltage - Nominal	-	27.25 V
Voltage - Output 1	28.25 V	28.25 V
Weight	-	3000 g

BATT CHRGR ENCLOSED 27.25V 14.5A

Part	Battery Cell Size	Weight	Voltage - Input [Min]	Voltage - Input [Max]	Charge Current - Max [Max]	Battery Chemistry	Termination Style	Voltage - Nominal	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Mounting Type	Type	Number of Cells	Approval Agency	Operating Temperature [Min]	Operating Temperature [Max]	Power - Max [Max]	Features	Voltage - Output 1	Voltage - Isolation	Efficiency	Number of Outputs	Power (Watts)	Current - Output 1	Applications
Bel Power Solutions UT1240-7Z	24 V	3000 g	85 VAC	255 VAC	14.5 A	Lead Acid	Terminal Block	27.25 V	6.63 "	111 mm	4.4 in	141.5 mm	5.57 "	168.5 mm	DIN Rail	Enclosed	1	cCSAus, CE	-25 °C	71 °C	500 W	LED Indicator
Bel Power Solutions UT1240-7ZG			70 VAC	140 VAC					6.6 "	111 mm	4.4 in	141 mm	5.6 "	168 mm	Chassis Mount	Conformal Coated, Enclosed		cCSAus, CE	-25 °C	71 °C		Adjustable Output, Hot Swappable, Load Sharing, Universal Input	28.25 V	2.8 kV	91 %	1	500 W	14.5 A	ITE (Commercial)
