FGS.2F.310.XLM
ActiveLEMO
CONN PLUG FMALE 10POS GOLD CRIMP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
FGS.2F.310.XLM
ActiveLEMO
CONN PLUG FMALE 10POS GOLD CRIMP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | FGS.2F.310.XLM | FGS.2F Series |
|---|---|---|
| Applications | Aerospace | Aerospace |
| Cable Opening [custom] | 14 mm | 14 mm |
| Cable Opening [custom] | 0.551 in | 0.551 in |
| Color | Gray | Silver, Gray |
| Connector Type | Female Sockets, Plug | Female Sockets, Plug |
| Contact Finish - Mating | Gold | Gold |
| Contact Finish Thickness - Mating | 59 Áin | 59 Áin |
| Contact Finish Thickness - Mating | 1.5 Ám | 1.5 Ám |
| Contact Material | Bronze | Bronze |
| Current Rating (Amps) | 8 A | 5 - 10 A |
| Fastening Type | Push-Pull | Push-Pull |
| Ingress Protection | IP67 - Dust Tight, Waterproof | IP67 - Dust Tight, Waterproof |
| Insert Material | Polyetheretherketone (PEEK) | Polyetheretherketone (PEEK) |
| Material Flammability Rating | UL94 V-0 | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) |
| Number of Positions | 10 | 8 - 19 |
| Operating Temperature [Max] | 200 °C | 200 °C |
| Operating Temperature [Min] | -15 °C | -55 - -15 °C |
| Orientation | S | S |
| Primary Material | Metal | Metal |
| Shell Finish | Nickel | Chrome, Nickel |
| Shell Material | Aluminum Alloy | Brass, Aluminum Alloy |
| Shell Size - Insert | 310 | 308 - 319 |
| Shielding | Shielded | Shielded |
| Termination | Crimp | Crimp |
FGS.2F Series
CONN PLUG FMALE 12POS GOLD CRIMP
| Part | Applications | Contact Material | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Primary Material | Current Rating (Amps) | Fastening Type | Ingress Protection | Mounting Type | Cable Opening [custom] | Cable Opening [custom] | Shell Size - Insert | Orientation | Connector Type | Material Flammability Rating | Number of Positions | Shielding | Operating Temperature [Min] | Operating Temperature [Max] | Insert Material | Termination | Shell Material | Contact Finish - Mating | Shell Finish | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LEMO FGS.2F.312.CLM | Aerospace | Bronze | 59 Áin | 1.5 Ám | Metal | 7 A | Push-Pull | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line) | 14 mm | 0.551 in | 312 | S | Female Sockets, Plug | UL94 V-0 | 12 | Shielded | -55 °C | 200 °C | Polyetheretherketone (PEEK) | Crimp | Brass | Gold | Chrome | Silver |
LEMO FGS.2F.308.XLM | Aerospace | Bronze | 59 Áin | 1.5 Ám | Metal | 10 A | Push-Pull | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line) | 14 mm | 0.551 in | 308 | S | Female Sockets, Plug | UL94 V-0 | 8 | Shielded | -15 °C | 200 °C | Polyetheretherketone (PEEK) | Crimp | Aluminum Alloy | Gold | Nickel | Gray |
LEMO FGS.2F.319.XLMS | Aerospace | Bronze | 59 Áin | 1.5 Ám | Metal | 5 A | Push-Pull | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line) | 14 mm | 0.551 in | 319 | S | Female Sockets, Plug | UL94 V-0 | 19 | Shielded | -15 °C | 200 °C | Polyetheretherketone (PEEK) | Crimp | Aluminum Alloy | Gold | Nickel | Gray |
LEMO FGS.2F.319.XLM | Aerospace | Bronze | 59 Áin | 1.5 Ám | Metal | 5 A | Push-Pull | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line) | 14 mm | 0.551 in | 319 | S | Female Sockets, Plug | UL94 V-0 | 19 | Shielded | -15 °C | 200 °C | Polyetheretherketone (PEEK) | Crimp | Aluminum Alloy | Gold | Nickel | Gray |
LEMO FGS.2F.312.XLM | Aerospace | Bronze | 59 Áin | 1.5 Ám | Metal | 7 A | Push-Pull | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line) | 14 mm | 0.551 in | 312 | S | Female Sockets, Plug | UL94 V-0 | 12 | Shielded | -15 °C | 200 °C | Polyetheretherketone (PEEK) | Crimp | Aluminum Alloy | Gold | Nickel | Gray |
LEMO FGS.2F.310.XLM | Aerospace | Bronze | 59 Áin | 1.5 Ám | Metal | 8 A | Push-Pull | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line) | 14 mm | 0.551 in | 310 | S | Female Sockets, Plug | UL94 V-0 | 10 | Shielded | -15 °C | 200 °C | Polyetheretherketone (PEEK) | Crimp | Aluminum Alloy | Gold | Nickel | Gray |
LEMO FGS.2F.319.CLM | Aerospace | Bronze | 59 Áin | 1.5 Ám | Metal | 5 A | Push-Pull | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line) | 14 mm | 0.551 in | 319 | S | Female Sockets, Plug | UL94 V-0 | 19 | Shielded | -55 °C | 200 °C | Polyetheretherketone (PEEK) | Crimp | Brass | Gold | Chrome | Silver |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 116.17 | |
| 10 | $ 98.75 | |||
| 25 | $ 92.57 | |||
| 50 | $ 88.16 | |||
| 100 | $ 85.76 | |||
Description
General part information
FGS.2F Series
10 Position Circular Connector Plug, Female Sockets Crimp
