Technical Specifications
Parameters and characteristics for this part
| Specification | RR0306P-221-D |
|---|---|
| Composition | Thin Film |
| Height - Seated (Max) | 0.01 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 0201 (0603 Metric) |
| Power (Watts) | 50 mW |
| Power (Watts) Options | 1/20W |
| Resistance | 220 Ohm |
| Size / Dimension Length | 0.024 in |
| Size / Dimension Width | 0.012 in |
| Temperature Coefficient | 25 ppm/°C |
| Tolerance | 0.5 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | Updated |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.19 | 30d+ |
| 10 | $ 0.14 | |||
| 50 | $ 0.11 | |||
| 100 | $ 0.10 | |||
| 500 | $ 0.07 | |||
| 1000 | $ 0.07 | |||
| Digi-Reel® | 1 | $ 0.19 | 30d+ | |
| 10 | $ 0.14 | |||
| 50 | $ 0.11 | |||
| 100 | $ 0.10 | |||
| 500 | $ 0.07 | |||
| 1000 | $ 0.07 | |||
| N/A | 8085 | $ 0.11 | 30d+ | |
| Tape & Reel (TR) | 5000 | $ 0.05 | 30d+ | |
| 10000 | $ 0.05 | |||
| Newark | Each (Supplied on Full Reel) | 5000 | $ 0.09 | 30d+ |
| 10000 | $ 0.08 | |||
| 20000 | $ 0.07 | |||
| 30000 | $ 0.05 | |||
CAD
3D models and CAD resources for this part
Description
General part information
RR0306P-221-D
220 Ohms ±0.5% 0.05W, 1/20W Chip Resistor 0201 (0603 Metric) Thin Film
Documents
Technical documentation and resources
