Description
General part information
TGHDX270RJE
270 Ohms ±5% 100W Thick Film Chassis Mount Resistor
Technical Specifications
Parameters and characteristics for this part
| Specification | TGHDX270RJE |
|---|---|
| Coating | Epoxy Coated |
| Composition | Thick Film |
| Features | Current Sense, Non-Inductive |
| Height - Seated (Max) | 0.236 in |
| Housing Type | Epoxy Coated |
| Lead Style | Wire Leads |
| Mounting Feature | Flanges |
| Operating Temperature (Max) | 155 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | SOT-227-2 |
| Power (Watts) | 100 W |
| Resistance | 270 Ohm |
| Size / Dimension Length | 1.26 in |
| Size / Dimension Width | 0.748 in |
| Temperature Coefficient | 100 ppm/°C |
| Tolerance | 5 % |
