MAX11253EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL KIT FOR MAX11253
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAX11253EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL KIT FOR MAX11253
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX11253EVKIT# | MAX11253 Series |
|---|---|---|
| Architecture | - | Sigma-Delta |
| Configuration | - | MUX-PGA-ADC |
| Data Interface | - | SPI |
| Features | - | PGA |
| Input Type | - | Differential |
| Mounting Type | - | Surface Mount |
| Number of A/D Converters | - | 1 |
| Number of Bits | 16 | 16 |
| Number of Inputs | - | 6 |
| Operating Temperature | - | 125 °C |
| Operating Temperature | - | -40 °C |
| Reference Type | - | External |
| Sampling Rate (Per Second) | 64k | 64k |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 32-TQFN (5x5) |
| Utilized IC / Part | MAX11253 | MAX11253 |
| Voltage - Supply, Analog | - | 2.7 V |
| Voltage - Supply, Analog | - | 1.8 V |
| Voltage - Supply, Analog | - | 3.6 V |
| Voltage - Supply, Digital | - | 3.6 V |
| Voltage - Supply, Digital | - | 1.7 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
MAX11253 Series
IC ADC 16BIT SIGMA-DELTA 32TQFN
| Part | Number of Inputs | Data Interface | Operating Temperature [Max] | Operating Temperature [Min] | Supplier Device Package | Features | Voltage - Supply, Digital [Max] | Voltage - Supply, Digital [Min] | Mounting Type | Reference Type | Configuration | Number of A/D Converters | Number of Bits | Voltage - Supply, Analog [Min] | Voltage - Supply, Analog | Voltage - Supply, Analog [Max] | Sampling Rate (Per Second) | Architecture | Input Type | Supplied Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX11253ATJ+ | 6 | SPI | 125 °C | -40 °C | 32-TQFN (5x5) | PGA | 3.6 V | 1.7 V | Surface Mount | External | MUX-PGA-ADC | 1 | 16 | 2.7 V | 1.8 V | 3.6 V | 64k | Sigma-Delta | Differential | ||
Analog Devices Inc./Maxim Integrated MAX11253ATJ+T | 6 | SPI | 125 °C | -40 °C | 32-TQFN (5x5) | PGA | 3.6 V | 1.7 V | Surface Mount | External | MUX-PGA-ADC | 1 | 16 | 2.7 V | 1.8 V | 3.6 V | 64k | Sigma-Delta | Differential | ||
Analog Devices Inc./Maxim Integrated MAX11253EVKIT# | 16 | 64k | Board(s) | MAX11253 |
Description
General part information
MAX11253 Series
MAX11253 - 16 Bit 64k Samples per Second Analog to Digital Converter (ADC) Evaluation Board
