4282-5SG-3ES
ActiveConxall/Switchcraft
CONN RCPT FMALE 5P GOLD SLDR CUP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
4282-5SG-3ES
ActiveConxall/Switchcraft
CONN RCPT FMALE 5P GOLD SLDR CUP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 4282-5SG-3ES | 4282-5S Series |
|---|---|---|
| Color | Black | Black |
| Connector Type | Receptacle, Female Sockets | Receptacle, Female Sockets |
| Contact Finish - Mating | Gold | Gold |
| Contact Material | Brass | Brass |
| Current Rating (Amps) | 5.6 A | 5.6 A |
| Fastening Type | Bayonet Lock | Bayonet Lock |
| Ingress Protection | Weathertight | Weathertight |
| Mounting Feature | Bulkhead - Front Side Nut | Bulkhead - Front Side Nut |
| Operating Temperature [Max] | 115 °C | 115 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Orientation | Keyed | Keyed |
| Primary Material | Plastic | Plastic |
| Shielding | Unshielded | Unshielded |
| Voltage Rating | 600 V | 600 V |
4282-5S Series
CONN RCPT FMALE 5P GOLD SLDR CUP
| Part | Orientation | Connector Type | Color | Mounting Feature | Primary Material | Voltage Rating | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Shielding | Ingress Protection | Contact Finish - Mating | Fastening Type | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Conxall/Switchcraft 4282-5SG-300 | Keyed | Receptacle, Female Sockets | Black | Bulkhead - Front Side Nut | Plastic | 600 V | -40 °C | 115 °C | Brass | Unshielded | Weathertight | Gold | Bayonet Lock | 5.6 A |
Conxall/Switchcraft 4282-5SG-3ES | Keyed | Receptacle, Female Sockets | Black | Bulkhead - Front Side Nut | Plastic | 600 V | -40 °C | 115 °C | Brass | Unshielded | Weathertight | Gold | Bayonet Lock | 5.6 A |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 100 | $ 10.85 | |
Description
General part information
4282-5S Series
5 Position Circular Connector Receptacle, Female Sockets Solder Cup
