83335E 009500

Active

Belden Inc.

CABLE 3CON 20AWG WHT SHLD

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 3CON 20AWG WHT SHLD

Technical Specifications

Parameters and characteristics for this part

Specification	83335E 009500

Cable Type	Multi-Conductor
Conductor Insulation	Tetrafluoroethylene (TFE)
Conductor Material	Copper, Silver Coated
Conductor Strand [custom]	19
Conductor Strand [custom]	32 AWG
Jacket (Insulation) Diameter [diameter]	4.27 mm
Jacket (Insulation) Diameter [diameter]	0.168 in
Jacket (Insulation) Material	Tetrafluoroethylene (TFE)
Jacket (Insulation) Thickness	0.254 mm
Jacket (Insulation) Thickness	0.01 in
Length [x]	500 '
Length [x]	152.4 m
Number of Conductors	3
Operating Temperature [Max]	200 °C
Operating Temperature [Min]	-65 ░C
Shield Coverage	85 %
Shield Material	Copper, Silver Coated
Shield Type	Braid
Voltage	600 V
Wire Gauge	20 AWG

Part	Length	Length	Conductor Insulation	Shield Type	Conductor Material	Wire Gauge	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Material	Operating Temperature [Min]	Operating Temperature [Max]	Number of Conductors	Shield Material	Voltage	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Shield Coverage	Cable Type	Length [x]	Length [x]
Belden Inc. 83335E 0091000	1000 ft	304.8 m	Tetrafluoroethylene (TFE)	Braid	Copper Silver Coated	20 AWG	19	32 AWG	Tetrafluoroethylene (TFE)	-65 ░C	200 °C	3	Copper Silver Coated	600 V	0.254 mm	0.01 in	4.27 mm	0.168 in	85 %	Multi-Conductor
Belden Inc. 83335E 009500			Tetrafluoroethylene (TFE)	Braid	Copper Silver Coated	20 AWG	19	32 AWG	Tetrafluoroethylene (TFE)	-65 ░C	200 °C	3	Copper Silver Coated	600 V	0.254 mm	0.01 in	4.27 mm	0.168 in	85 %	Multi-Conductor	500 '	152.4 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	500	$ 13.84

General part information

3 Conductor Multi-Conductor Cable White 20 AWG Braid 500.0' (152.4m)
