Description
General part information
KHD500E107M90C0B00
100 µF ±20% 50V Ceramic Capacitor Y5U (E) Radial
Technical Specifications
Parameters and characteristics for this part
| Specification | KHD500E107M90C0B00 |
|---|---|
| Applications | SMPS Filtering |
| Capacitance | 100 µF |
| Height - Seated (Max) | 0.787 in |
| Lead Spacing | 0.787 in |
| Lead Style | Straight |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial |
| Size / Dimension Length | 0.886 in |
| Size / Dimension Width | 0.236 in |
| Temperature Coefficient | Y5U (E) |
| Tolerance | 20 % |
| Voltage - Rated | 50 V |
