Specification	MTA206PA

Actuator Length	10.49 mm
Actuator Material	Chrome Plated, Copper Alloy
Actuator Type	Standard Round
Bushing Thread	1/4-40
Circuit	SP3T
Current Rating	4 A, 6 A
Electrical Life (Cycles)	60000
Features	Jumper needed to achieve triple throw
Illumination	Non-Illuminated
Mounting Type	Panel Mount
Operating Temperature (Max)	80 °C
Operating Temperature (Min)	-20 °C
Panel Cutout Diameter	6.4 mm
Panel Cutout Shape	Circular
Switch Function	On-On-On
Termination Style	Solder Lug
Voltage Rating - AC	125 V
Voltage Rating - DC	28 V

MTA206 Series

Part	Actuator Material	Electrical Life (Cycles)	Circuit	Current Rating	Mounting Type	Actuator Length	Voltage Rating - DC	Switch Function	Termination Style	Bushing Thread	Operating Temperature (Min)	Operating Temperature (Max)	Panel Cutout Diameter	Panel Cutout Shape	Actuator Type	Features	Voltage Rating - AC	Illumination
TE Connectivity AMP Connectors MTA206SA	Chrome Plated Copper Alloy	60000	SP3T	4 A 6 A	Panel Mount	10.49 mm	28 V	Mom-On-Mom	Solder Lug	1/4-40	-20 °C	80 °C	6.4 mm	Circular	Standard Round	Jumper needed to achieve triple throw	125 V	Non-Illuminated
TE Connectivity AMP Connectors MTA206SPC	Brass Nickel Plated		DPDT	4 A 6 A	Panel Mount	10.49 mm	28 V	Mom-Off-Mom	PC Pin	1/4-40	-20 °C	80 °C			Standard Round	Epoxy Sealed Terminals	125 V	Non-Illuminated
TE Connectivity AMP Connectors MTA206TPC	Chrome Plated Copper Alloy	60000	DPDT	4 A 6 A	Panel Mount	10.49 mm	28 V	On-Off-Mom	PC Pin	1/4-40	-20 °C	80 °C	6.4 mm	Circular	Standard Round	Epoxy Sealed Terminals	125 V	Non-Illuminated
TE Connectivity AMP Connectors MTA206N	Brass Nickel Plated	80000 Cycles	DPDT	4 A 6 A	Panel Mount	10.49 mm	28 V	On-On	Solder Lug	1/4-40	-20 °C	80 °C	6.4 mm	Circular	Standard Round	Epoxy Sealed Terminals	125 V	Non-Illuminated
TE Connectivity AMP Connectors MTA206T	Chrome Plated Copper Alloy	60000	DPDT	4 A 6 A	Panel Mount	10.49 mm	28 V	On-Off-Mom	Solder Lug	1/4-40	-20 °C	80 °C	6.4 mm	Circular	Standard Round	Epoxy Sealed Terminals	125 V	Non-Illuminated
TE Connectivity AMP Connectors MTA206SPC			DPDT	4 A 6 A	Panel Mount	10.49 mm	28 V	Mom-Off-Mom	PC Pin	1/4-40	-20 °C	80 °C			Standard Round	Epoxy Sealed Terminals	125 V	Non-Illuminated
TE Connectivity AMP Connectors MTA206PPC			DPDT	4 A 6 A	Panel Mount	10.49 mm	28 V	On-Off-On	PC Pin	1/4-40	-20 °C	80 °C			Standard Round	Epoxy Sealed Terminals	125 V	Non-Illuminated
TE Connectivity AMP Connectors MTA206RPC	Brass Nickel Plated		DPDT	4 A 6 A	Panel Mount	10.49 mm	28 V	On-Mom	PC Pin	1/4-40	-20 °C	80 °C			Standard Round	Epoxy Sealed Terminals	125 V	Non-Illuminated
TE Connectivity AMP Connectors MTA206PPC	Brass Nickel Plated		DPDT	4 A 6 A	Panel Mount	10.49 mm	28 V	On-Off-On	PC Pin	1/4-40	-20 °C	80 °C			Standard Round	Epoxy Sealed Terminals	125 V	Non-Illuminated
TE Connectivity AMP Connectors MTA206N			DPDT	4 A 6 A	Panel Mount	10.49 mm	28 V	On-On	Solder Lug	1/4-40	-20 °C	80 °C	6.4 mm	Circular	Standard Round	Epoxy Sealed Terminals	125 V	Non-Illuminated
