DB2C-A1RC
ActiveZF Electronics
SWITCH SNAP ACTION SPDT 10A 125V
Deep-Dive with AI
Search across all available documentation for this part.
DB2C-A1RC
ActiveZF Electronics
SWITCH SNAP ACTION SPDT 10A 125V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | DB2C-A1RC |
|---|---|
| Actuator Type | Roller, Lever |
| Circuit | SPDT |
| Current Rating (Amps) | 10 A |
| Differential Travel | 1 mm |
| Differential Travel | 0.04 in |
| Electrical Life | 6000 Cycles |
| Ingress Protection | IP50 |
| Mechanical Life | 10000000 Cycles |
| Mounting Type | Chassis Mount |
| Operating Force | 95 gf |
| Operating Position | 0.638 in |
| Operating Position | 16.2 mm |
| Operating Temperature [Max] | 120 °C |
| Operating Temperature [Min] | -40 °C |
| Overtravel | 1.5 mm |
| Overtravel | 0.06 " |
| Pretravel | 0.197 in |
| Pretravel | 5 mm |
| Switch Function | On-Mom |
| Termination Style | Solder Lug |
| Voltage Rating - AC | 125 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 32 | $ 2.25 | |
| 64 | $ 2.11 | |||
| 512 | $ 2.06 | |||
Description
General part information
DB2C-A1RC
Switch SPDT Chassis Mount
Documents
Technical documentation and resources
No documents available
