Description
General part information
ESL105M450AE3DA
Aluminum Electrolytic Capacitors
Technical Specifications
Parameters and characteristics for this part
| Specification | ESL105M450AE3DA |
|---|---|
| Applications | General Purpose |
| Capacitance | 1 µF |
| ESR (Equivalent Series Resistance) | 33 Ohm |
| Height - Seated (Max) | 0.492 in |
| Lead Spacing | 0.197 in |
| Lifetime | 8000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can, Radial |
| Polarization | Polar |
| Ripple Current | 50 mA, 25 mA |
| Size / Dimension Diameter | 0.248 in |
| Tolerance | 20 % |
| Voltage - Rated | 450 V |
