PCSDR127-390M-RC
ActiveAllied Components International
39UH +/-20% POWER CHIP SHIELDED
PCSDR127-390M-RC
ActiveAllied Components International
39UH +/-20% POWER CHIP SHIELDED
Description
General part information
PCSDR127-390M-RC
39 µH Shielded Inductor 3.131 A 76.4mOhm Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | PCSDR127-390M-RC |
|---|---|
| Current - Saturation (Isat) | 5.71 A |
| Current Rating | 3.131 A |
| DC Resistance (DCR) | 76.4 mOhm |
| Height - Seated (Max) | 0.315 in |
| Inductance | 39 µH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.492 in |
| Size / Dimension Width | 0.492 in |
| Tolerance | 20 % |
