PEG226KG4120QE4

PEG226KG4120QE4

Active
KEMET

CAP ALUM 1200UF 40V AXIAL TH

Find alt
PEG226KG4120QE4

PEG226KG4120QE4

Active
KEMET

CAP ALUM 1200UF 40V AXIAL TH

Find alt

Description

General part information

PEG226KG4120QE4

1200 µF 40 V Aluminum Electrolytic Capacitors Axial, Can 69mOhm @ 100Hz 1500 Hrs @ 150°C

Technical Specifications

Parameters and characteristics for this part

SpecificationPEG226KG4120QE4
ApplicationsAutomotive
Capacitance1200 µF
ESR (Equivalent Series Resistance)69 mOhm
Lifetime1500 Hrs
Mounting TypeThrough Hole
Operating Temperature (Max)150 °C
Operating Temperature (Min)-40 °C
Package / CaseCan, Axial
PolarizationPolar
RatingsAEC-Q200
Ripple Current6.51 A, 18.6 A
Size / Dimension Diameter0.638 in
Size / Dimension Length1.366 in
Tolerance (Negative)10 %
Tolerance (Positive)30 %
Voltage - Rated40 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Sign in to see pricing

Create a free account to access distributor pricing data.

Sign up — freeLog in

CAD

3D models and CAD resources for this part
