EVM-31GA00B15
ObsoletePanasonic Electronic Components
TRIMMER 100KOHM 0.3W PC PIN SIDE
EVM-31GA00B15
ObsoletePanasonic Electronic Components
TRIMMER 100KOHM 0.3W PC PIN SIDE
Description
General part information
EVM-31GA00B15
100 kOhms 0.3W PC Pins Through Hole Trimmer Potentiometer Cermet 1.0 Turn Side Adjustment
Technical Specifications
Parameters and characteristics for this part
| Specification | EVM-31GA00B15 |
|---|---|
| Adjustment Type | Side Adjustment |
| Mounting Type | Through Hole |
| Number of Turns | 1 turns |
| Power (Watts) | 300 mW |
| Resistance | 100 kOhm |
| Resistive Material | Cermet |
| Size / Dimension Length | 0.268 in |
| Size / Dimension Shape | Square |
| Size / Dimension Width | 0.268 in |
| Temperature Coefficient | 200 ppm/°C |
| Termination Style | PC Pins |
| Tolerance | 25 % |
