100023252
ActiveTelegartner Inc
MULTIPIN B 20 DIN41622 STR
100023252
ActiveTelegartner Inc
MULTIPIN B 20 DIN41622 STR
Description
General part information
100023252
20 Position Din Connector Header, Male Pins Tin Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 100023252 |
|---|---|
| Connector Type | Header, Male Pins |
| Contact Finish | Tin |
| Current Rating | 6 A |
| Features | Mounting Clips |
| Material - Insulation | PC, Polycarbonate |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Positions | 20 |
| Number of Positions Loaded | All |
| Number of Rows | 2 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Style | B |
| Termination | Solder |
