B72241L0421K100
ActiveEPCOS - TDK Electronics
VARISTOR 680V 50KA ENCASED DISC
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
B72241L0421K100
ActiveEPCOS - TDK Electronics
VARISTOR 680V 50KA ENCASED DISC
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | B72241L0421K100 |
|---|---|
| Capacitance @ Frequency | 1800 pF |
| Current - Surge | 50 kA |
| Energy | 910 J |
| Maximum AC Volts [Max] | 420 V |
| Maximum DC Volts [Max] | 560 V |
| Mounting Type | Chassis Mount |
| Number of Circuits | 1 |
| Operating Temperature [Max] | 85 C |
| Operating Temperature [Min] | -25 °C |
| Package / Case | Encased Disc |
| Varistor Voltage (Max) [Max] | 748 V |
| Varistor Voltage (Min) [Min] | 612 V |
| Varistor Voltage (Typ) | 680 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 100 | $ 12.94 | |
Description
General part information
B72241L Series
680 V 50 kA Varistor 1 Circuit Chassis Mount Encased Disc
