5432070
ActivePhoenix Contact
TERM BLOCK HDR 13POS VERT 5MM
5432070
ActivePhoenix Contact
TERM BLOCK HDR 13POS VERT 5MM
Description
General part information
5432070
13 Position Terminal Block Header, Male Pins, Shrouded (2 Side) 0.197" (5.00mm) Vertical Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 5432070 |
|---|---|
| Color | Gray |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.154 in |
| Current - IEC | 12 A |
| Current - UL | 15 A |
| Header Orientation | Vertical |
| Housing Material | Nylon, Polyamide, PA |
| Insulation Height | 0.472 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 13 |
| Pitch | 0.197 in |
| Positions Per Level | 13 |
| Termination Style | Solder |
| Type | Male Pins, Shrouded (2 Side), Header |
| Voltage - IEC | 400 V |
| Voltage - UL | 300 V |
