TTC3A123J3743EY
ActiveThinking Electronics Industrial Co.
NTC THERMISTOR 3MM 12K OHM +/-5%
TTC3A123J3743EY
ActiveThinking Electronics Industrial Co.
NTC THERMISTOR 3MM 12K OHM +/-5%
Description
General part information
TTC3A123J3743EY
NTC Thermistor 12k Bead
Technical Specifications
Parameters and characteristics for this part
| Specification | TTC3A123J3743EY |
|---|---|
| B Value (25/85) | 3740 K |
| B Value Tolerance | 3 % |
| Length - Lead Wire | 1.58 in |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Bead |
| Power - Max | 150 mW |
| Resistance (Ohms) | 12 kOhm |
| Resistance Tolerance (%) | 5 % |
