5MF 3.5-R
ObsoleteBEL MAGNETIC SOLUTIONS
FUSE GLASS 3.5A 125VAC 5X20MM
Deep-Dive with AI
Search across all available documentation for this part.
5MF 3.5-R
ObsoleteBEL MAGNETIC SOLUTIONS
FUSE GLASS 3.5A 125VAC 5X20MM
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 5MF 3.5-R |
|---|---|
| Approval Agency | PSE, CE, cULus, CSA |
| Current Rating (Amps) | 3.5 A |
| DC Cold Resistance | 0.025 Ohms |
| Melting I²t | 17 |
| Mounting Type | Requires Holder |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case [x] | 5 mm |
| Package / Case [y] | 20 mm |
| Response Time | Fast Blow |
| Size / Dimension [diameter] | 5.1 mm |
| Size / Dimension [diameter] | 0.201 in |
| Size / Dimension [x] | 0.787 in |
| Size / Dimension [x] | 20 mm |
| Voltage Rating - AC | 125 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 0.67 | |
| 5 | $ 0.56 | |||
| 10 | $ 0.52 | |||
| 50 | $ 0.43 | |||
| 100 | $ 0.40 | |||
| 250 | $ 0.36 | |||
| 500 | $ 0.33 | |||
| 1000 | $ 0.30 | |||
| 5000 | $ 0.25 | |||
Description
General part information
5MF 3.5-R
3.5 A 125 V AC DC Fuse Cartridge, Glass Requires Holder 5mm x 20mm
Documents
Technical documentation and resources
No documents available
