MS6524F
ObsoleteInventus Power
AC/DC CONVERTER 24V 65W
MS6524F
ObsoleteInventus Power
AC/DC CONVERTER 24V 65W
Description
General part information
MS6524F
Open Frame AC DC Converters 1 Output 24V 85 ~ 264 VAC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | MS6524F |
|---|---|
| Applications | Medical |
| Approval Agency | CB, CE |
| Current - Output 1 | 2.7 A |
| Efficiency | 87 % |
| Features | Universal Input |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | 0 °C |
| Power (Watts) | 65 W |
| Size / Dimension Height | 1.15 in |
| Size / Dimension Length | 5 in |
| Size / Dimension Width | 2.99 in |
| Type | Open Frame |
| Voltage - Input (AC) Maximum | 264 V |
| Voltage - Input (AC) Minimum | 85 VAC |
| Voltage - Output 1 | 24 V |
