000209 Series

Part	Contact Finish	Wire Gauge (AWG) (Max)	Wire Gauge (AWG) (Min)	Pin or Socket	Contact Termination	Contact Finish Thickness	Type	Contact Material
Molex 0002091153	Tin	18 AWG	14 AWG	Socket	Crimp	20 µin	Power
Molex 0002091139	Tin	24 AWG	22 AWG	Socket	Crimp	20 µin	Power
Molex 0002095133	Gold	22 AWG	18 AWG	Socket	Crimp	50 µin
Molex 0002091116
Molex 0002095147	Gold	30 AWG	24 AWG	Socket	Crimp	15 µin	Power
Molex 0002092127	Tin	22 AWG	18 AWG	Pin	Crimp	20 µin	Power
Molex 0002096106	Gold	20.5 AWG	14 AWG	Pin	Crimp	15 µin	Power Stamped	Brass
Molex 0002091104	Tin	20.5 AWG	14 AWG	Socket	Crimp	20 µin	Power
Molex 0002091143
Molex 0002091102	Tin	20.5 AWG	14 AWG	Socket	Crimp	20 µin	Power

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources

No documents available
