DG507AMWI/PR
ActiveAnalog Devices Inc./Maxim Integrated
IC SWITCH SP8TX2 400OHM 28SOIC
Deep-Dive with AI
Search across all available documentation for this part.
DG507AMWI/PR
ActiveAnalog Devices Inc./Maxim Integrated
IC SWITCH SP8TX2 400OHM 28SOIC
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | DG507AMWI/PR | DG507 Series |
|---|---|---|
| - | - | |
| Channel Capacitance (CS(off), CD(off)) [custom] | 6 pF | 6 - 45 pF |
| Channel Capacitance (CS(off), CD(off)) [custom] | 6 pF | 6 pF |
| Channel-to-Channel Matching (ΔRon) | 24 Ohm | 24 Ohm |
| Current - Leakage (IS(off)) (Max) | 1 nA | 1 - 5 nA |
| Mounting Type | Surface Mount | Surface Mount, Through Hole |
| Multiplexer/Demultiplexer Circuit | 8:1 | 8:1 |
| Number of Circuits | 2 | 2 |
| On-State Resistance (Max) [Max] | 400 Ohm | 400 - 450 Ohm |
| Operating Temperature [Max] | 125 °C | 70 - 125 °C |
| Operating Temperature [Min] | -55 °C | -55 - 0 °C |
| Package / Case | 28-SOIC | 28-SOIC, 28-DIP |
| Package / Case | - | 0.6 in |
| Package / Case | - | 15.24 mm |
| Package / Case [x] | 0.295 in | 0.295 in |
| Package / Case [y] | 7.5 mm | 7.5 mm |
| Supplier Device Package | 28-SOIC | 28-SOIC, 28-PDIP |
| Switch Circuit | SP8T - Open/Closed | SP8T - Open/Closed |
| Switch Time (Ton, Toff) (Max) [custom] | 400 ns | 400 ns |
| Switch Time (Ton, Toff) (Max) [custom] | 1 µs | 1 µs |
| Voltage - Supply, Dual (V±) [Max] | 18 V | 18 V |
| Voltage - Supply, Dual (V±) [Min] | -4.5 V | -4.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 15 | $ 20.43 | |
DG507 Series
450Ω SOIC-28-300MIL ANALOG SWITCHES, MULTIPLEXERS ROHS
| Part | Number of Circuits | Package / Case | Package / Case [x] | Package / Case [y] | Mounting Type | Current - Leakage (IS(off)) (Max) | Supplier Device Package | On-State Resistance (Max) [Max] | Switch Time (Ton, Toff) (Max) [custom] | Switch Time (Ton, Toff) (Max) [custom] | Voltage - Supply, Dual (V±) [Max] | Voltage - Supply, Dual (V±) [Min] | Channel Capacitance (CS(off), CD(off)) [custom] | Channel Capacitance (CS(off), CD(off)) [custom] | Multiplexer/Demultiplexer Circuit | Operating Temperature [Max] | Operating Temperature [Min] | Package / Case | Package / Case | Channel-to-Channel Matching (ΔRon) | Switch Circuit |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated DG507ACWI+T | 2 | 28-SOIC | 0.295 in | 7.5 mm | Surface Mount | 5 nA | 28-SOIC | 450 Ohm | 400 ns | 1 µs | 18 V | -4.5 V | 6 pF | 45 pF | 8:1 | 70 °C | 0 °C | ||||
Analog Devices Inc./Maxim Integrated DG507ACWI+T | |||||||||||||||||||||
Analog Devices Inc./Maxim Integrated DG507ACJ+ | 2 | 28-DIP | Through Hole | 5 nA | 28-PDIP | 450 Ohm | 400 ns | 1 µs | 18 V | -4.5 V | 6 pF | 45 pF | 8:1 | 70 °C | 0 °C | 0.6 in | 15.24 mm | ||||
Analog Devices Inc./Maxim Integrated DG507AMWI/PR | 2 | 28-SOIC | 0.295 in | 7.5 mm | Surface Mount | 1 nA | 28-SOIC | 400 Ohm | 400 ns | 1 µs | 18 V | -4.5 V | 6 pF | 6 pF | 8:1 | 125 °C | -55 °C | 24 Ohm | SP8T - Open/Closed |
Description
General part information
DG507 Series
2 Circuit IC Switch 8:1 400Ohm 28-SOIC
