8505 008100
ActiveBelden Inc.
HOOK-UP STRND 26AWG GRAY
Deep-Dive with AI
Search across all available documentation for this part.
8505 008100
ActiveBelden Inc.
HOOK-UP STRND 26AWG GRAY
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 8505 008100 |
|---|---|
| Cable Type | Hook-Up |
| Conductor Material | Copper, Tinned |
| Conductor Strand | 7 Strands, 34 AWG |
| Jacket (Insulation) Diameter [diameter] | 0.039 in |
| Jacket (Insulation) Diameter [diameter] | 0.99 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Thickness | 0.25 mm |
| Jacket (Insulation) Thickness | 0.01 in |
| Jacket Color | Gray |
| Length [x] | 30.5 m |
| Length [x] | 100 ft |
| Qualification | MIL-W-16878/1 Type B |
| Voltage | 600 V |
| Wire Gauge | 26 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 100 | $ 1.09 | |
| 200 | $ 1.04 | |||
| 300 | $ 1.01 | |||
| 500 | $ 0.97 | |||
| 700 | $ 0.95 | |||
| 1000 | $ 0.92 | |||
| 2500 | $ 0.86 | |||
| 5000 | $ 0.82 | |||
| 10000 | $ 0.78 | |||
Description
General part information
8505 Series
26 AWG Hook-Up Wire 7/34 Gray 600V 100.0' (30.5m)
