12.86509
ActiveGeyer Electronic America, Inc.
CYSTAL 48.0MHZ 10PF SMD
12.86509
ActiveGeyer Electronic America, Inc.
CYSTAL 48.0MHZ 10PF SMD
Description
General part information
12.86509
48 MHz ±50ppm Crystal 10pF 50 Ohms 4-SMD, Flat Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | 12.86509 |
|---|---|
| ESR (Equivalent Series Resistance) | 50 Ohm |
| Frequency | 48 MHz |
| Frequency Stability | 30 ppm |
| Frequency Tolerance | 50 ppm |
| Height - Seated (Max) | 0.022 in |
| Load Capacitance | 10 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -20 °C |
| Package / Case | 4-SMD, Flat Leads |
| Size / Dimension Length | 0.098 in |
| Size / Dimension Width | 0.079 in |
| Type | MHz Crystal |
