LCAS8-10F-L
ObsoletePanduit Corp
CONN TERM RECT TONG 8 AWG #10
LCAS8-10F-L
ObsoletePanduit Corp
CONN TERM RECT TONG 8 AWG #10
Description
General part information
LCAS8-10F-L
Terminal Connector Rectangular Rectangular Tongue 8 AWG 10 Stud
Technical Specifications
Parameters and characteristics for this part
| Specification | LCAS8-10F-L |
|---|---|
| Color | Red |
| Contact Finish | Electro-Tin |
| Contact Material | Copper |
| Diameter - Barrel ID | 0.18 in |
| Diameter - Barrel OD | 0.27 in |
| Diameter - Ring ID | 0.2 in |
| Insulation | Non-Insulated |
| Mounting Type | Right Angle, Free Hanging (In-Line) |
| Stud/Tab Size | 10 Stud |
| Tab Thickness | 0.08 in |
| Terminal Style | Single Stud Hole |
| Terminal Type | Rectangular Tongue |
| Termination | Barrel, Crimb |
| Width - Outer Edges | 0.41 in |
| Wire Gauge | 8 AWG |
