ISO-24-AFA

Active

ATC-Diversified Electronics

SINGLE CHANNEL ISOLATED SWITCH

Search across all available documentation for this part.

Active

ATC-Diversified Electronics

SINGLE CHANNEL ISOLATED SWITCH

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	ISO-24-AFA	ISO-24 Series

Approval Agency	UL	UL
Coil Type	Non Latching	Non Latching
Coil Voltage	24 VAC	24 VAC
Contact Form	SPST-NO (1 Form A)	SPST-NO (1 Form A)
Contact Rating (Current)	5 A	5 A
Mounting Type	Socketable	Chassis Mount, Socketable
Operate Time	6 ms	6 ms
Operating Temperature [Max]	55 °C	55 °C
Operating Temperature [Min]	-20 C	-20 C
Relay Type	General Purpose	General Purpose
Release Time	2.5 ms	2.5 ms
Switching Voltage	120 VAC	120 VAC
Termination Style	Plug In, 8 Pin (Octal)	Screw Terminal, Plug In, 8 Pin (Octal)

SINGLE CHANNEL ISOLATED SWITCH

Part	Release Time	Operating Temperature [Max]	Operating Temperature [Min]	Contact Form	Operate Time	Switching Voltage	Approval Agency	Contact Rating (Current)	Coil Voltage	Mounting Type	Termination Style	Relay Type	Coil Type
ATC-Diversified Electronics ISO-24-AFN	2.5 ms	55 °C	-20 C	SPST-NO (1 Form A)	6 ms	120 VAC	UL	5 A	24 VAC	Chassis Mount	Screw Terminal	General Purpose	Non Latching
ATC-Diversified Electronics ISO-24-AFA	2.5 ms	55 °C	-20 C	SPST-NO (1 Form A)	6 ms	120 VAC	UL	5 A	24 VAC	Socketable	Plug In, 8 Pin (Octal)	General Purpose	Non Latching

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 185.57

General part information

General Purpose Relay SPST-NO (1 Form A) 24VAC Coil Socketable
