Specification	4950CIR-0.75(5)

Adhesive	Acrylic
Backing	Paper
Carrier	Paper
Color	White
Shelf Life	24 Months
Shelf Life Start	Date of Shipment
Storage/Refrigeration Temperature (Maximum)	100 °F
Storage/Refrigeration Temperature (Minimum)	40 °F
Tape Type	Double Sided, Double Coated
Temperature Range (Max)	200 °F
Thickness	0.045 in
Thickness - Adhesive	0.042 in
Thickness - Backing, Carrier	0.003 in
Width	0.75 in

4950 Series

...

Part	Storage/Refrigeration Temperature (Minimum)	Storage/Refrigeration Temperature (Maximum)	Shelf Life Start	Shelf Life	Thickness - Adhesive	Color	Thickness	Tape Type	Carrier	Backing	Thickness - Backing, Carrier	Width	Adhesive	Temperature Range (Max)	Length	Length (yd)	Length (ft)	Usage	Temperature Range (Single)
3M (TC) 3M 4950 0.5" X 6"-25	40 °F	100 °F	Date of Shipment	24 Months	0.042 in	White	0.045 in	Double Coated Double Sided	Paper	Paper	0.003 in	12.7 mm	Acrylic	200 °F	0.5 ft
3M (TC) 3M 4950 5" X 10"-5	40 °F	100 °F	Date of Shipment	24 Months	0.042 in	White	0.045 in	Double Coated Double Sided	Paper	Paper	0.003 in	5 in	Acrylic	200 °F	10 in
3M (TC) 4950-1.5-3(25)	40 °F	100 °F	Date of Shipment	24 Months	0.042 in	White	0.045 in	Double Coated Double Sided	Paper	Paper	0.003 in	1.5 in	Acrylic	200 °F	3 "
3M (TC) 4950-1.25-5	40 °F	100 °F	Date of Shipment	24 Months	0.042 in	White	0.045 in	Double Coated Double Sided	Paper	Paper	0.003 in	1.25 in	Acrylic	200 °F		5 yd	15 ft
3M (TC) 4950-1-5(15)	40 °F	100 °F	Date of Shipment	24 Months	0.042 in	White	0.045 in	Double Coated Double Sided	Paper	Paper	0.003 in	1 in	Acrylic	200 °F	5 in
3M (TC) 3M 4950 2" X 10"-6	40 °F	100 °F	Date of Shipment	24 Months	0.042 in	White	0.045 in	Double Coated Double Sided	Paper	Paper	0.003 in	2 in	Acrylic	200 °F	10 in
3M (TC) 4950-6-9(2)	40 °F	100 °F	Date of Shipment	24 Months	0.042 in	White	0.045 in	Double Coated Double Sided	Paper	Paper	0.003 in	6 in	Acrylic	200 °F	228.6 mm
3M (TC) 7-5-4950	40 °F	100 °F	Date of Shipment	24 Months	0.042 in	White	0.045 in	Double Coated Double Sided	Paper	Paper	0.003 in	7 in	Acrylic	200 °F		5 yd	15 ft
3M (TC) 4950-0.5-4(5)	40 °F	100 °F	Date of Shipment	24 Months	0.042 in	White	0.045 in	Double Coated Double Sided	Paper	Paper	0.003 in	12.7 mm	Acrylic	200 °F	4 in
3M (TC) 4950-3-5	40 °F	100 °F	Date of Shipment	24 Months	0.042 in	White	0.045 in	Double Coated Double Sided	Paper	Paper	0.003 in	3 in	Acrylic			5 yd	15 ft	General Purpose	200 °F

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

4950CIR-0.75(5) | Datasheet
