Specification	1784952

Color	Green
Contact Mating Finish	Silver
Contact Tail Length	0.181 in
Current - IEC	125 A
Current - UL	115 A
Features	Mating and Mounting Flange
Header Orientation	Right Angle
Header Orientation Angle	90 °
Housing Material	PBT, Polybutylene Terephthalate
Insulation Height	1.122 in
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Levels	1
Number of Positions	6
Pitch	0.591 in
Positions Per Level	6
Termination Style	Solder
Type	Blade Sockets, Header
Voltage - IEC	1000 V
Voltage - UL	600 V
