1838893-3
ActiveTE Connectivity AMP Connectors
SENSOR CONNECTOR, M12, PLUG, 5POS
1838893-3
ActiveTE Connectivity AMP Connectors
SENSOR CONNECTOR, M12, PLUG, 5POS
Description
General part information
1838893-3
5 Position Circular Connector, Wire-to-Panel, Sealable, Wire & Cable, Signal, Panel Mount & Board Mount, Reverse Gender, Plastic, M12 Connector
Technical Specifications
Parameters and characteristics for this part
| Specification | 1838893-3 |
|---|---|
| Color | Silver |
| Connector Type | Male Pins, Plug |
| Contact Finish - Mating | Gold |
| Current Rating | 5 A |
| Fastening Type | Threaded |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Mounting Feature | Rear Side Nut, Bulkhead |
| Mounting Type | Panel Mount |
| Number of Positions | 5 |
| Operating Temperature (Max) | 90 °C |
| Operating Temperature (Min) | -25 °C |
| Orientation | Keyed |
| Primary Material | Metal |
| Shell Finish | Nickel |
| Shell Material | Zinc Die Cast |
| Shell Size - Insert | M12-5 |
| Termination | Solder Cup |
| Voltage Rating | 60 V |
| Voltage Rating (Type) | DC |
